16 | PACE Calibration Manual–English
After completing the calibration procedures, adjust the pressure calibration standard to
atmospheric pressure.
13. Recommended Calibration Check Points
Barometric
Variant
2 bara / 1 barg up to 21 bara / 20 barg
750 mbar 35 mbara / -965 mbarg
900 mbar 20% of full-scale pressure
950 mbar 40% of full-scale pressure
1050 mbar 60% of full-scale pressure
1150 mbar 80% of full-scale pressure
1050 mbar 100% of full-scale pressure
1000 mbar 80% of full-scale pressure
950 mbar 60% of full-scale pressure
900 mbar 40% of full-scale pressure
750 mbar 20% of full-scale pressure
- 35 mbara / -965 mbarg
36 bara / 35 barg and Above All Other Variants (700 mbarg and Below)
Atmospheric / 0 mbarg 0 mbarg
20% of full-scale pressure -100% of full-scale pressure
40% of full-scale pressure -80% of full-scale pressure
60% of full-scale pressure -60% of full-scale pressure
80% of full-scale pressure -40% of full-scale pressure
100% of full-scale pressure -20% of full-scale pressure
80% of full-scale pressure 0 mbarg
60% of full-scale pressure 20% of full-scale pressure
40% of full-scale pressure 40% of full-scale pressure
20% of full-scale pressure 60% of full-scale pressure
Atmospheric / 0 mbarg 80% of full-scale pressure
- 100% of full-scale pressure
- 0 mbarg
