Section 6: Programming Worksheets
Description on page 64
003– Repeater 3 Label:
004– Repeater 4 Label:
005– Repeater 5 Label:
006– Repeater 6 Label:
007– Repeater 7 Label:
008– Repeater 8 Label:
[000] 999 – Default Labels
Description on page 64
6.2 Zone Setup
[001] [001 - 128] Zone Type
Available Zone Types
Default = 000
Description on page 64
* Not UL evaluated
000 – Null Zone
001 – Delay 1
002 – Delay 2
003 – Instant
004 – Interior
005 – Interior Stay/Away
006 – Delay Stay/Away
007 – Delayed 24-Hour Fire
008 – Standard 24-Hour Fire
009 – Instant Stay/Away
010 – Interior Delay
011 – Day Zone
012 – Night Zone
016 – Final Door Set
017 – 24-Hour Burglary
018 – 24-Hour Bell/Buzzer
023 – 24-Hour Supervisory
024 – 24-Hour Supervisory Buzzer
025 – Auto Verified Fire
027 – Fire Supervisory
040 – 24-Hour Gas
041 – 24-Hour CO
042 – 24-Hour Holdup*
043 – 24-Hour Panic
045 – 24-Hour Heat
046 – 24-Hour Medical
047 – 24-Hour Emergency
048 – 24-Hour Sprinkler*
049 – 24-Hour Flood
051 – 24-Hour Latching Tamper
052 – 24-Hour Non-Alarm
056 – 24-Hour High Temperature
057 – 24 Hour Low Temperature
060 – 24-Hour Non-Latching Tamper
066 – Momentary Keyswitch Arm
067 – Maintained Keyswitch Arm
068 – Momentary Keyswitch Disarm
069 – Maintained Keyswitch Disarm
071 – Door Bell
072 – Push to Set
[002] [001 - 128] Zone Attributes
Available Zone Attributes
See next page for defaults
Description on page 68
1 – Bell Audible
2 – Bell Steady
3 – Door Chime
4 – Bypass Enabled
5 – Force Arm
6 – Swinger Shutdown
7 – Transmission Delay
8 – Burglary Verification
9 – Normally Close
10 – Single EOL
11 – Double EOL
12 – Fast/Normal Loop Response
13 – Zone 2-way Audio Activation
14 – Hold Up Verification
- 127 -
