DSC HS2016 Reference Manual

Section 6: Programming Worksheets
001 – Partition 8 Auto-Arming Times:
24-Hour:
(4-digit HH:MM)
Sunday: Thursday:
Default: 9999
Monday: Friday:
Tuesday: Saturday:
Wednesday:
002 – Partition 8 Auto-Disarm Times:
24-Hour:
(4-digit HH:MM)
Sunday: Thursday:
Default: 9999
Monday: Friday:
Tuesday: Saturday:
Wednesday:
003 – Partition 8 Auto-Disarming Holiday Schedule:
Holiday 1: o On R Off
(3-digit decimal)
Holiday 2: o On R Off
Holiday 3: o On R Off
Holiday 4: o On R Off
004 – Partition 8 Auto-Arming Pre-Alert (Default: 004):
005 – Partition 8 Auto-Arming Postpone Timer (Default: 000):
006 – Partition 8 No Activity Arming Timer (Default: 000):
007 – Partition 8 No Activity Arming Pre-Alert Timer (Default: 001):
[200]
Partition Mask
001 – Partition 1 to 8
Enable Mask
R – Partition 1
o – Partition 2
Descriptions on page 99
o – Partition 3
o – Partition 4
o – Partition 5
o – Partition 6
o – Partition 7
o – Partition 8
6.9 Partition and Zone Assignment
[201]-[208] Partition Zone Assignment
(Description on page 99)
[201] Partition 1 Zone Assignment [202] Partition 2 Zone Assignment
Bit 1 2 3 4 5 6 7 8 Bit 1 2 3 4 5 6 7 8
001 – 01-08
R R R R R R R R
001 – 01-08
o o o o o o o o
002 – 09-16
R R R R R R R R
002 – 09-16
o o o o o o o o
003 – 17-24
o o o o o o o o
003 – 17-24
o o o o o o o o
004 – 25-32
o o o o o o o o
004 – 25-32
o o o o o o o o
005 – 33-40
o o o o o o o o
005 – 33-40
o o o o o o o o
006 – 41-48
o o o o o o o o
006 – 41-48
o o o o o o o o
- 151 -
