DSC HS2016 Reference Manual

Section 6: Programming Worksheets
6.22 Wireless Placement Testing
6.22.1 Testing
[904] Wireless Placement Test
Description on page 120
001-128 – Placement Test - Zone 1-128
521-528 – Placement Test Repeaters 1-8
551-566 – Placement Test Sirens 1-16
601-632 – Placement Test Wireless Keys 1-32
701-716 – Placement Test Wireless Keypads 1-16
[912] Zone Soak Test
Description on page 121
000 – Zone Soak Test Duration (3-digit decimal; 001-255 Days; Default: 014):
001 – Zone Soak Test Assignment - Zones 1-8
002 – Zone Soak Test Assignment - Zones 9-16
003 – Zone Soak Test Assignment - Zones 17-24
004 – Zone Soak Test Assignment - Zones 25-32
005 – Zone Soak Test Assignment - Zones 33-40
006 – Zone Soak Test Assignment - Zones 41-48
007 – Zone Soak Test Assignment - Zones 49-56
008 – Zone Soak Test Assignment - Zones 57-64
009 – Zone Soak Test Assignment - Zones 65-72
010 – Zone Soak Test Assignment - Zones 73-80
011 – Zone Soak Test Assignment - Zones 81-88
012 – Zone Soak Test Assignment - Zones 89-96
013 – Zone Soak Test Assignment - Zones 97-104
014 – Zone Soak Test Assignment - Zones 105-112
015 – Zone Soak Test Assignment - Zones 113-120
016 – Zone Soak Test Assignment - Zones 121-128
6.23 Battery Settings
[982] Battery Settings
Description on page 121
000 – Panel Battery Settings 01 – o Panel High Charge Current
010 – HSM2204 High Current Output Battery
01 – o HSM2204 1 High Charge Current
02 – o HSM2204 2 High Charge Current
03 – o HSM2204 3 High Charge Current
04 – o HSM2204 4 High Charge Current
020 – HSM2300 1A Power Supply Battery
01 – o HSM2300 1 High Charge Current
- 178 -

DSC HS2016 Specifications

General

Mounting Type	Wall mount
Power Supply	16.5VAC
Battery Backup	12VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Dimensions	267mm
