DSC HS2016 Reference Manual

Section 6: Programming Worksheets
Day (Default : 000):
Hour
(Default :
NA
002
EN
001):
Increment (Default : 001):
6.4 Access Codes
[006] Installer-Defined Codes
(4/6/8-Digit Decimal)
001 – Installer Code
(Default:55555555)
(4/6/8-Digit Decimal)
002 – Master Code
(Default:12345678)
(4/6/8-Digit Decimal)
003 – Maintenance Code
(Default: AAAAAAAA)
(000-255)
005 – Code Version
(Default:000)
6.5 PGM Programming
[007] [000 - 164] PGM Programming
[000] – Main Bell Partition Assignment
1 2 3 4 5 6 7 8
Y N N N N N N N
[001 – 164] PGM Partition Assignment
Default: Partition 1 on. All others off
Description on page 77
1 2 3 4 5 6 7 8
Y N N N N N N N
[008] [000 - 164] PGM Timer Programming
[000] – PGM Timers Minutes or Seconds:
o Minutes o Seconds
[001 – 164]: PGM 1 to 164
(3-Digit Decimal)
Valid Range: 001-255
Default: 005
Description on page 72
001 – PGM 1: 002 – PGM 2: 003 – PGM 3: 004 – PGM 4:
005 – PGM 5: 006 – PGM 6: 007 – PGM 7: 008 – PGM 8:
009 – PGM 9: 010 – PGM 10: 011 – PGM 11: 012 – PGM 12:
013 – PGM 13: 014 – PGM 14: 015 – PGM 15: 016 – PGM 16:
017 – PGM 17: 018 – PGM 18: 019 – PGM 19: 020 – PGM 20:
021 – PGM 21: 022 – PGM 22: 023 – PGM 23: 024 – PGM 24:
025 – PGM 25: 026 – PGM 26: 027 – PGM 27: 028 – PGM 28:
029 – PGM 29: 030 – PGM 30: 031 – PGM 31: 032 – PGM 32:
033 – PGM 33: 034 – PGM 34: 035 – PGM 35: 036 – PGM 36:
037 – PGM 37: 038 – PGM 38: 039 – PGM 39: 040 – PGM 40:
041 – PGM 41: 042 – PGM 42: 043 – PGM 43: 044 – PGM 44:
045 – PGM 45: 046 – PGM 46: 047 – PGM 47: 048 – PGM 48:
049 – PGM 49: 050 – PGM 50: 051 – PGM 51: 052 – PGM 52:
053 – PGM 53: 054 – PGM 54: 055 – PGM 55: 056 – PGM 56:
- 131 -
