DSC HS2016 Reference Manual

Section 6: Programming Worksheets
[308] Event Reporting
Description on page 101
314 – Maintenance Events 4
R 1 – Gas Trouble
R 2 – Gas Trouble Restore
R 3 – Heat Trouble
R 4 – Heat Trouble Restore
R 5 – Freeze Trouble
R 6 – Freeze Trouble Restore
R 7 – Probe Disconnected Trouble
R 8 – Probe Disconnected Restore
321 – Receiver Events
R2 – Receiver 1 FTC Restore
R4 – Receiver 2 FTC Restore
R6 – Receiver 3 FTC Restore
R8 – Receiver 4 FTC Restore
331 – Module Events 1
R1 – Module AC Trouble
R2 – Module AC Trouble Restore
R 3 – Module Battery Trouble
R 4 – Module Battery Trouble Restore
R 5 – Module Battery Absent
R 6 – Module Battery Absent Restore
332 – Module Events 2
R 1 – Module Low Voltage Trouble
R 2 – Module Low Voltage Restore
R 3 – Module Supervisory
R 4 – Module Supervisory Restore
R 5 – Module Aux Trouble
R 6 – Module Aux Trouble Restore
335 – Module Events 5
R 1 – Output 1 Fault
R 2 – Output 1 Fault Restore
351 – Alternate
Communicator 1
R 1 – Alt. Comm. Module Comm Fault
R 2 – Alt. Comm. Module Comm Fault Restore
R 7 – Alt. Comm. Radio/SIM Failure
R8 – Alt. Comm. Radio/SIM Failure Restore
352 – Alternate
Communicator 2
R 1 – Alt. Comm. Network Fault
R 2 – Alt. Comm. Network Fault Restore
R 5 – Alt. Comm. Ethernet Trouble
R 6 – Alt. Comm. Ethernet Trouble Restore
354 – Alternate
Communicator 4
R 1 – Alt. Comm Receiver 1 Trouble
R 2 – Alt. Comm Receiver 1 Restore
R 3 – Alt. Comm Receiver 2 Trouble
R 4 – Alt. Comm Receiver 2 Restore
R 5 – Alt. Comm Receiver 3 Trouble
R 6 – Alt. Comm Receiver 3 Restore
R 7 – Alt. Comm Receiver 4 Trouble
R 8 – Alt. Comm Receiver 4 Restore
- 158 -

DSC HS2016 Specifications

General

Mounting Type	Wall mount
Power Supply	16.5VAC
Battery Backup	12VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Dimensions	267mm
