DSC HS2016 Reference Manual

Section 6: Programming Worksheets
05 – o Thursday
06 – o Friday
07 – o Saturday
[604] Programming Schedule 4
Interval 1
101 – Start Time: 102 – End Time:
103 – Days Assignment: 104 – Holiday Assignment:
(4- digit decimal)
01 – o Sunday o Holiday 1
HH:MM to HH:MM
02 – o Monday o Holiday 2
Default: 0000
03 – o Tuesday o Holiday 3
04 – o Wednesday o Holiday 4
05 – o Thursday
06 – o Friday
07 – o Saturday
Interval 2
201 – Start Time: 202 – End Time:
203 – Days Assignment: 204 – Holiday Assignment:
(4- digit decimal)
01 – o Sunday o Holiday 1
HH:MM to HH:MM
02 – o Monday o Holiday 2
Default: 0000
03 – o Tuesday o Holiday 3
04 – o Wednesday o Holiday 4
05 – o Thursday
06 – o Friday
07 – o Saturday
Interval 3
301 – Start Time: 302 – End Time:
303 – Days Assignment: 304 – Holiday Assignment:
(4- digit decimal)
01 – o Sunday o Holiday 1
HH:MM to HH:MM
02 – o Monday o Holiday 2
Default: 0000
03 – o Tuesday o Holiday 3
04 – o Wednesday o Holiday 4
05 – o Thursday
06 – o Friday
07 – o Saturday
Interval 4
401 – Start Time: 402 – End Time:
403 – Days Assignment: 404 – Holiday Assignment:
(4- digit decimal)
01 – o Sunday o Holiday 1
HH:MM to HH:MM
02 – o Monday o Holiday 2
Default: 0000
03 – o Tuesday o Holiday 3
04 – o Wednesday o Holiday 4
05 – o Thursday
06 – o Friday
07 – o Saturday
[711] Holiday Group 1
(6-Digit Decimal)
001 – Holiday Group 1 Date 1:
- 167 -

DSC HS2016 Specifications

General

Mounting Type	Wall mount
Power Supply	16.5VAC
Battery Backup	12VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Dimensions	267mm
