DSC HS2016 Reference Manual

Appendix 1: Reporting Codes
Section # Definition
Dialer Dir-
ection*
Automatic Contact ID
Codes
SIA Auto Rep Codes**
[308]-[101] Siren 6 tamper/restore alarm T/R E(3)83-806 / R (3)83-806 TA-0806 / TR-0806
[308]-[101] Siren 7 tamper/restore alarm T/R E(3)83-807 / R (3)83-807 TA-0807 / TR-0807
[308]-[101] Siren 8 tamper/restore alarm T/R E(3)83-808 / R (3)83-808 TA-0808 / TR-0808
[308]-[101] Siren 9 tamper/restore alarm T/R E(3)83-809 / R (3)83-809 TA-0809 / TR-0809
[308]-[101] Siren 10 tamper/restore alarm T/R E (3)83-810 / R (3)83-810 TA-0810 / TR-0810
[308]-[101] Siren 11 tamper/restore alarm T/R E(3)83-811 / R (3)83-811 TA-0811 / TR-0811
[308]-[101] Siren 12 tamper/restore alarm T/R E (3)83-812 / R (3)83-812 TA-0812 / TR-0812
[308]-[101] Siren 13 tamper/restore alarm T/R E(3)83-813 / R (3)83-813 TA-0813 / TR-0813
[308]-[101] Siren 14 tamper/restore alarm T/R E (3)83-814 / R (3)83-814 TA-0814 / TR-0814
[308]-[101] Siren 15 tamper/restore alarm T/R E(3)83-815 / R (3)83-815 TA-0815 / TR-0815
[308]-[101] Siren 16 tamper/restore alarm T/R E (3)83-816 / R (3)83-816 TA-0816 / TR-0816
[308]-[101] Repeater 1 tamper/restore alarm T/R E(3)83-901 / R (3)83-901 TA-0901 / TR-0901
[308]-[101] Repeater 2 tamper/restore alarm T/R E(3)83-902 / R (3)83-902 TA-0902 / TR-0902
[308]-[101] Repeater 3 tamper/restore alarm T/R E(3)83-903 / R (3)83-903 TA-0903 / TR-0903
[308]-[101] Repeater 4 tamper/restore alarm T/R E(3)83-904 / R (3)83-904 TA-0904 / TR-0904
[308]-[101] Repeater 5 tamper/restore alarm T/R E(3)83-905 / R (3)83-905 TA-0905 / TR-0905
[308]-[101] Repeater 6 tamper/restore alarm T/R E(3)83-906 / R (3)83-906 TA-0906 / TR-0906
[308]-[101] Repeater 7 tamper/restore alarm T/R E(3)83-907 / R (3)83-907 TA-0907 / TR-0907
[308]-[101] Repeater 8 tamper/restore alarm T/R E(3)83-908 / R (3)83-908 TA-0908 / TR-0908
[308]-[101] HSM2108: 8-Zone Expander module #1 tamper/restored T/R E(3)41-101 / R(3)41-101 ES-0101 / EJ-0101
[308]-[101] HSM2108: 8-Zone Expander module #2 tamper/restored T/R E(3)41-102 / R(3)41-102 ES-0102 / EJ-0102
[308]-[101] HSM2108: 8-Zone Expander module #3 tamper/restored T/R E(3)41-103 / R(3)41-103 ES-0103 / EJ-0103
[308]-[101] HSM2108: 8-Zone Expander module #4 tamper/restored T/R E(3)41-104 / R(3)41-104 ES-0104 / EJ-0104
[308]-[101] HSM2108: 8-Zone Expander module #5 tamper/restored T/R E(3)41-105 / R(3)41-105 ES-0105 / EJ-0105
[308]-[101] HSM2108: 8-Zone Expander module #6 tamper/restored T/R E(3)41-106 / R(3)41-106 ES-0106 / EJ-0106
[308]-[101] HSM2108: 8-Zone Expander module #7 tamper/restored T/R E(3)41-107 / R(3)41-107 ES-0107 / EJ-0107
[308]-[101] HSM2108: 8-Zone Expander module #8 tamper/restored T/R E(3)41-108 / R(3)41-108 ES-0108 / EJ-0108
[308]-[101] HSM2108: 8-Zone Expander module #9 tamper/restored T/R E(3)41-109 / R(3)41-109 ES-0109 / EJ-0109
[308]-[101] HSM2108: 8-Zone Expander module #10 tamper/restored T/R E(3)41-110 / R(3)41-110 ES-0110 / EJ-0110
[308]-[101] HSM2108: 8-Zone Expander module #11 tamper/restored T/R E(3)41-111 / R(3)41-111 ES-0111 / EJ-0111
[308]-[101] HSM2108: 8-Zone Expander module #12 tamper/restored T/R E(3)41-112 / R(3)41-112 ES-0112 / EJ-0112
[308]-[101] HSM2108: 8-Zone Expander module #13 tamper/restored T/R E(3)41-113 / R(3)41-113 ES-0113 / EJ-0113
[308]-[101] HSM2108: 8-Zone Expander module #14 tamper/restored T/R E(3)41-114 / R(3)41-114 ES-0114 / EJ-0114
[308]-[101] HSM2108: 8-Zone Expander module #15 tamper/restored T/R E(3)41-115 / R(3)41-115 ES-0115 / EJ-0115
[308]-[101] HSM2208: 8-Output Expander module #1 tamper/restored T/R E(3)41-201 / R(3)41-201 ES-0201 / EJ-0201
[308]-[101] HSM2208: 8-Output Expander module #12 tamper/restored T/R E(3)41-202 / R(3)41-202 ES-0202 / EJ-0202
[308]-[101] HSM2208: 8-Output Expander module #13 tamper/restored T/R E(3)41-203 / R(3)41-203 ES-0203 / EJ-0203
[308]-[101] HSM2208: 8-Output Expander module #14 tamper/restored T/R E(3)41-204 / R(3)41-204 ES-0204 / EJ-0204
[308]-[101] HSM2208: 8-Output Expander module #15 tamper/restored T/R E(3)41-205 / R(3)41-205 ES-0205 / EJ-0205
[308]-[101] HSM2208: 8-Output Expander module #15 tamper/restored T/R E(3)41-206 / R(3)41-206 ES-0206 / EJ-0206
[308]-[101] HSM2208: 8-Output Expander module #17 tamper/restored T/R E(3)41-207 / R(3)41-207 ES-0207 / EJ-0207
[308]-[101] HSM2208: 8-Output Expander module #18 tamper/restored T/R E(3)41-208 / R(3)41-208 ES-0208 / EJ-0208
[308]-[101] HSM2208: 8-Output Expander module #19 tamper/restored T/R E(3)41-209 / R(3)41-209 ES-0209 / EJ-0209
[308]-[101] HSM2208: 8-Output Expander module #10 tamper/restored T/R E(3)41-210 / R(3)41-210 ES-0210 / EJ-0210
[308]-[101] HSM2208: 8-Output Expander module #11 tamper/restored T/R E(3)41-211 / R(3)41-211 ES-0211 / EJ-0211
- 189 -
