DSC HS2016 Reference Manual

Appendix 1: Reporting Codes
Section # Definition
Dialer Dir-
ection*
Automatic Contact ID
Codes
SIA Auto Rep Codes**
Module Troubles
[308]-[332] Hardwired Module Low Voltage trouble/restore - Keypads MA/R
E(3)AA-001-016
R(3)AA-001-016
EM-0001-0016
EN-0001-0016
[308]-[332] Hardwired Module Low Voltage trouble/restore - HSM2108 MA/R
E (3)AA-101-116
R (3)AA-101-116
EM-0101-0116
EN-0101-0116
[308]-[332] Hardwired Module Low Voltage trouble/restore - HSM2208 MA/R
E(3)AA-201-216
R(3)AA-201-216
EM-0201-0216
EN-0201-0216
[308]-[332] Hardwired Module Low Voltage trouble/restore - HSM2HOST MA/R
E (3)AA-551
R (3)AA-551
EM-0551
EN-0551
[308]-[332] Hardwired Module Low Voltage trouble/restore - HSM2204 MA/R
E(3)AA-601-604
R(3)AA-601-604
EM-0601-0601
EN-0601-0604
[308]-[332] Hardwired Module Low Voltage trouble/restore - HSM2300 MA/R
E (3)AA-621-624
R (3)AA-621-624
EM-0621-0624
EN-0621-0624
[308]-[332] Hardwired Module Low Voltage trouble/restore - HSM2955 MA/R
E(3)AA-553
R(3)AA-553
EM-0553
EN-0553
[308]-[332] Hardwired Module Supervisory trouble/restore - Keypads MA/R
E(3)3A-001-016
R(3)3A-001-016
ET-0001-0032
ER-0001-0032
[308]-[332] Hardwired Module Supervisory trouble/restore - HSM2108 MA/R
E (3)3A-101-116
R (3)3A-101-116
ET-0101-0162
ER-0101-0162
[308]-[332] Hardwired Module Supervisory trouble/restore - HSM2208 MA/R
E(3)3A-201-216
R(3)3A-201-216
ET-0201-0216
ER-0201-0216
[308]-[332] Hardwired Module Supervisory trouble/restore - HSM2HOST MA/R
E(3)3A-551
R(3)3A-551
ET-0551
ER-0551
[308]-[332] Hardwired Module Supervisory trouble/restore - HSM2204 MA/R
E (3)3A-601-604
R (3)3A-601-604
ET-0601-0601
ER-0601-0604
[308]-[332] Hardwired Module Supervisory trouble/restore - HSM2300 MA/R
E(3)3A-621-624
R(3)3A-621-624
ET-0621-0624
ER-0621-0624
[308]-[332] Hardwired Module Supervisory trouble/restore - HSM2955 MA/R
E(3)3A-553
R(3)3A-553
ET-0553
ER-0553
[308]-[332] HSM2204 Aux Supply 1 trouble/restore MA/R
E(3)12-601
R(3)12-601
YI-0601 / YJ-0601
[308]-[332] HSM2204 Aux Supply 2 trouble/restore MA/R
E(3)12-602
R(3)12-602
YI-0602 / YJ-0602
[308]-[332] HSM2204 Aux Supply 3 trouble/restore MA/R
E(3)12-603
R(3)12-603
YI-0603 / YJ-0603
[308]-[332] HSM2204 Aux Supply 4 trouble/restore MA/R
E(3)12-604
R(3)12-604
YI-0604 / YJ-0604
[308]-[332] HSM2300 Aux Supply 1 trouble/restore MA/R
E(3)12-621
R(3)12-621
YI-0621 / YJ-0621
[308]-[332] HSM2300 Aux Supply 2 trouble/restore MA/R
E(3)12-622
R(3)12-622
YI-0622 / YJ-0622
[308]-[332] HSM2300 Aux Supply 3 trouble/restore MA/R
E(3)12-623
R(3)12-623
YI-0623 / YJ-0623
[308]-[332] HSM2300 Aux Supply 4 trouble/restore MA/R
E(3)12-624
R(3)12-624
YI-0624 / YJ-0624
[308]-[332] HSM2204 1 Low Battery trouble/restore MA/R
E(3)A2-601
R(3)A2-601
YT-0601 / YR-0601
- 191 -
