DSC HS2016 Reference Manual

Appendix 3: Template Programming Tables
4 Receiver 1 SIA
[380] Comm Toggles 1 - Bit 1 Communications Enabled - On
[350] Communicator Formats - [001] Receiver 1 - 04 SIA
[350] Communicator Formats - [002] Receiver 2 - 04 SIA
[350] Communicator Formats - [003] Receiver 3 - 04 SIA
[350] Communicator Formats - [004] Receiver 4 - 04 SIA
[381] Comm Toggles 2 - Bit 2 Bell Ringback - Off
[384] Comm Backup - Bit 2 Receiver 2 Backup - Off
[384] Comm Backup - Bit 2 Receiver 2 Backup - Off
[384] Comm Backup - Bit 2 Receiver 2 Backup - Off
[300] Comm Path - [001] Receiver 1 - 01 PSTN
[300] Comm Path - [002] Receiver 2 - 01 PSTN
[300] Comm Path - [003] Receiver 3 - 01 PSTN
[300] Comm Path - [004] Receiver 4 - 01 PSTN
5 Receiver 1 CID
[380] Comm Toggles 1 - Bit 1 Communications Enabled - On
[350] Communicator Formats - [001] Receiver 1 - 03 CID
[350] Communicator Formats - [002] Receiver 2 - 03 CID
[350] Communicator Formats - [003] Receiver 3 - 03 CID
[350] Communicator Formats - [004] Receiver 4 - 03 CID
[384] Comm Backup - Bit 2 Receiver 2 Backup - Off
[384] Comm Backup - Bit 2 Receiver 2 Backup - Off
[384] Comm Backup - Bit 2 Receiver 2 Backup - Off
[300] Comm Path - [001] Receiver 1 - 01 PSTN
[300] Comm Path - [002] Receiver 2 - 01 PSTN
[300] Comm Path - [003] Receiver 3 - 01 PSTN
[300] Comm Path - [004] Receiver 4 - 01 PSTN
6 Receiver 1 and 2 CIA with backup
[380] Comm Toggles 1 - Bit 1 Communications Enabled - On
[350] Communicator Formats - [001] Receiver 1 - 03 CID
[350] Communicator Formats - [002] Receiver 2 - 03 CID
[350] Communicator Formats - [003] Receiver 3 - 03 CID
[350] Communicator Formats - [004] Receiver 4 - 03 CID
[384] Comm Backup - Bit 2 Receiver 2 Backup - On
[384] Comm Backup - Bit 2 Receiver 2 Backup - Off
[384] Comm Backup - Bit 2 Receiver 2 Backup - Off
[300] Comm Path - [001] Receiver 1 - 01 PSTN
[300] Comm Path - [002] Receiver 2 - 01 PSTN
[300] Comm Path - [003] Receiver 3 - 01 PSTN
[300] Comm Path - [004] Receiver 4 - 01 PSTN
Digit 4 – Reporting Code Configuration Options
Option Common Group Selected Troubles Openings/ Closings Zone Alarm Restore DLS/Installer Lead In/Out
1
ü ü
X
2
ü ü ü
X
3
ü ü ü
X
4
ü ü ü ü
X
5
ü ü
X
6
ü ü
X
- 199 -

DSC HS2016 Specifications

General

Mounting Type	Wall mount
Power Supply	16.5VAC
Battery Backup	12VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Dimensions	267mm
