Appendix 3: Template Programming Tables
Common Group
Common Group Common Group Programming
Set all reporting codes to automatic [308] Event Reporting - All Events On
Alarm/restore call directions enabled
[311][001] Partition 1 Alarm/Restore - Bit 1 Receiver 1 - On
[311][001] Partition 1 Alarm/Restore - Bit 2 Receiver 2 - Off
[311][001] Partition 1 Alarm/Restore - Bit 3 Receiver 3 - Off
[311][001] Partition 1 Alarm/Restore - Bit 4 Receiver 4 - Off
Tamper/restore call directions disabled
[311][002] Partition 1 Tamper/Restore - Bit 1 Receiver 1 - Off
[311][002] Partition 1 Tamper/Restore - Bit 2 Receiver 2 - Off
[311][002] Partition 1 Tamper/Restore - Bit 3 Receiver 3 - Off
[311][002] Partition 1 Tamper/Restore - Bit 4 Receiver 4 - Off
Opening/closing call directions disabled
[311][003] Partition 1 Open/Close - Bit 1 Receiver 1 - Off
[311][003] Partition 1 Open/Close - Bit 2 Receiver 2 - Off
[311][003] Partition 1 Open/Close - Bit 3 Receiver 3 - Off
[311][003] Partition 1 Open/Close - Bit 4 Receiver 4 - Off
Maintenance call directions enabled
[309][001] Maintenance - Bit 1 Receiver 1 - On
[309][001] Maintenance - Bit 2 Receiver 2 - Off
[309][001] Maintenance - Bit 3 Receiver 3 - Off
[309][001] Maintenance - Bit 4 Receiver 4 - Off
Test transmission call directions disabled
[309][002] Test Transmission - Bit 1 Receiver 1 - Off
[309][002] Test Transmission - Bit 2 Receiver 2 - Off
[309][002] Test Transmission - Bit 3 Receiver 3 - Off
[309][002] Test Transmission - Bit 4 Receiver 4 - Off
l Enables/Disables all Reporting Codes
l Selected Troubles - Enables the following Troubles
Selected Troubles Group Selected Troubles Programming
Battery
[308][301] - Bit 3 Panel Low Battery - On
[308][301] - Bit 4 Panel Low Battery Restore - On
[308][301] - Bit 5 Panel Battery Absent - On
[308][301] - Bit 6 Panel Battery Absent Restore - On
[308][331] - Bit 3 Module Low Battery - On
[308][331] - Bit 4 Module Low Battery Restore - On
[308][331] - Bit 5 Module Battery Absent - On
[308][331] - Bit 6 Module Battery Absent Restore - On
AC Failure
[308][301] - Bit 1 Panel AC Trouble - Off
[308][301] - Bit 2 Panel AC Trouble Restore - Off
[308][331] - Bit 1 Module AC Trouble - Off
[308][331] - Bit 2 Module AC Trouble Restore - Off
Bell Circuit Trouble
[308][302] - Bit 1 Panel Bell Trouble - On
[308][302] - Bit 2 Panel Bell Trouble Restore - On
Fire, Alarm
[308][311] - Bit 3 Fire Trouble - On
[308][311] - Bit 4 Fire Trouble Restore - On
[308][305] - Bit 3 2W Smoke Trouble - On
[308][305] - Bit 4 2W Smoke Trouble Restore - On
- 201 -
