Section 1: Introduction

Wireless PG curtain motion detector PGx924

Wireless PG dual tech motion detector PGx984(P)

Wireless PG mirror motion detector PGx974(P)

Wireless PG outdoor motion detector PGx994

Wireless PG glass break detector PGx912,PGx922

Wireless PG shock detector PGx935

Wireless PG flood detector PGx985

Wireless PG temperature detector (indoor use) PGx905

Outdoor temperature probe (requires PGx905) PGTEMP-PROBE

Wireless PG key PGx939

Wireless PG key PGx929

Wireless PG panic key PGx938

Wireless PG 2-button key PGx949

Wireless PG indoor siren PGx901

Wireless PG outdoor siren PGx911

Wireless PG repeater PGx920

Wireless PG door/window contact PGx975

Wireless PG door/window contact w/ AUX PGx945

Central Station Receivers

SG-System I, II, III, IV, 5

Enclosures

The PowerSeries Neo main board can be installed in the metal enclosures listed below: Tamper protection switches can be installed on all

enclosures, including door opening protection and/or removal from the mounting position. Doors can be secured using screws or keylock.

• Model PC5003C (removable door) made of 22Ga steel, painted, dimensions: 248mm(L) x 298mm(W) x 76mm(H), weight: 4.5Kg (with PCB,

7AH battery and transformer included)

• Model Power UC1 made of 18Ga steel, painted, dimensions: 315mm(L) x 319mm(W) x 100mm(H), weight: 6.15Kg (with PCB, 7AH battery and

transformer included).

Model PC4051C made of 18Ga steel, painted. 427mm(L) x 265mm(W) x 105mm(H).

For EN50131-1 Grade 2 compliant installations, allholes on the side of the cabinets shall be covered (plugged) if no accessories are installed in

the cabinet that will use these mounting holes.

The equipment enclosure shall be secured to the building structure before operation. Use 4 screws (appropriate for the wall material on which it is

attached) inserted through the four mounting holes provided in the back of the enclosure base.

- 9 -

DSC HS2016 Reference Manual
