DSC HS2016 User Guide

Chapter 7.0 Trouble Conditions
BusVoltage 03 Amodulehasdetectedalow
voltageonitscorbusredter-
minal.
HSM2HOST 01 n/a

Keypad 02 Keypad1-16

Zone
Expander
04 Zone
expander1-
15
PowerSupply 05 Powersup-
ply1-4
HighCurrent
Output
06 Outputter-
minal1-4

Output
Expander
08 Outputmod-
ule1-16

HSM2955Bus
Voltage
(Audio
Expander)
09

n/a

ACTroubles 04 Thesystemisexperiencing
lossofpower.Callforservice.
Ifthebuildingand/orneigh-
borhoodhaslostelectrical
power,thesystemwillcon-
tinuetooperateonbatteryfor
severalhours.
Zone 01 Zonelabel
or001-128

Siren 03 Siren1-16
Repeater 04 Repeater1-
8
PowerSupply 05 Powersup-
ply1-4
HighCurrent
Output
06 Outputter-
minal1-4
SystemLabel 07 n/a
DeviceFaults 05 Thesystemhasdetectedan
issuewithoneormorecon-
necteddevices.Callforser-
vice.
Gas
 
- 19 -

DSC HS2016 Specifications

General

Mounting Type	Wall mount
Power Supply	16.5VAC
Battery Backup	12VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Dimensions	267mm
