DSC HS2016 User Guide

Chapter 4.0 Arming the System
4.0 Arming the System
ThePowerSeriesNeosystemcanbearmedusingakeypad,a2-waywirelesskeyoraproximity
tag.
4.1 Away Arming the System with the Keypad
Awaymodeactivatesthecompletealarmsystemby:
l Armingallperimetersensors.
l Armingallinteriorsensors.
ToArmtheSysteminAwayMode LCDDisplay
1. EnsureallwindowsanddoorsareclosedandthattheReady
indicatorison.
Date Time
JAN 02/13 2:06a
2. ToarmusingtheAwaykey ,pressandholdtheAway
keyfor2secondsand,ifrequired,enteryour[accesscode]or
presentyourproximitytag.
OR
ToQuickArmthesystempress[*][0].
System is
Ready to Arm

then

Present Tag or
EnterCode
3. Ifzoneshavebeenbypassed,ICNorLEDkeypadsbypass
LED willlightandthebypassedzones#swillbeshown.
OnanLCDkeypadawarningappears.
* Warning *
Bypass Active
4. Aftersuccessfullyinitiatingthearmingsequencethe:
l
Armed indicatorturnson.
l
Ready indicatorremainslit.
l ExitDelaytimerbeginscountingdown.
l Keypadbeepssixtimes,continuesbeepingoncepersecond
untilbeepingrapidlyinthefinaltenseconds.
l Thesystemmaybeconfiguredtohaveapersistentexit
delaythatonlyendswhentheexitdoorisopenedand
closed,orwhenabuttonispressedoutsidetheprotected
premises.
Exit Delay in
Progress
5. Tocancelthearmingsequence,enteryour[accesscode]or
presentyourproximitytagtothekeypadreader.
System Disarmed
No Alarm Memory
6. Oncetheexitdelaytimerexpires,therebyarmingthesystem,
the:
l Readyindicatorturnsoff.
l Armedindicatorremainson.
l Keypadstopssounding.

System Armed
in Away Mode
Note:Theinstallerconfigurestheexitdelaytimerandwhetherornotanaccesscodeisrequired
forarmingthesystem.
- 9 -

DSC HS2016 Specifications

General

Mounting Type	Wall mount
Power Supply	16.5VAC
Battery Backup	12VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Dimensions	267mm
