K E Y P A D C O M M A N D S
16
[✱]+[4] Door Chime On/Off
If enabled the keypad will beep 5 times rapidly when a zone is tripped and restored. The panel will only
do this for zones with the Door Chime attribute enabled and if the door chime feature is enabled
(See
Section 5.2 “Zone Attributes”)
.
To turn Door Chime on/off:
1.Press [✱] [4].
2.The keypad will beep 3 times rapidly when the Door Chime feature is enabled and one long beep when
the feature is disabled.
[✱]+[5] Programming Access Codes
There are 37 Access Codes available. They are as follows:
• Access Codes [01] to [32] User Codes 1 to 32 • Access Code [40] ........... System Master Code
• Access Code [33]............ Partition Duress Code • Access Code [41] ........... Partition Master Code
• Access Code [34]............ Partition Duress Code • Access Code [42] ........... Partition Master Code
All Access Codes have the ability to arm/disarm any Partition(s) it is enabled for and activate the PGM Outputs
using the [✱][7][Access Code][1] and [✱][7][2] commands
(See Section 3.4 “[
✱
] Commands, [
✱
][7]”)
.
Additional Access Code Attributes are also programmable. Attributes determine what abilities the code
will have. The programmable attributes are as follows:
• Partition 1 Operation enable • Zone Bypass enable
• Partition 2 Operation enable • Escort5580 Access enable
User Codes - Access Codes [01] to [32]
Each User Code can be programmed to work on Partition 1, Partition 2 or both Partitions. In addition each
can be programmed to have the ability to bypass zones and remote access to the Escort5580.
“Master Code” attributes cannot change. By default, each code has the attributes of the code used to
program it.
Duress Codes - Access Codes [33] and [34]
When a Duress Code is used to perform any function the panel will report a Duress Reporting Code
(See
Section 5.7 “Communicator - Reporting Codes”)
.
Partition Master Codes - Access Codes [41] and [42]
Partition Master Codes can program additional User Codes and the Duress Code for their Partition.
System Master Code - Access Code [40]
By default the System Master Code is enabled to operate on both Partitions and can perform any keypad
function. This code can be used to program all User Codes as well as the Partition Master Codes and
Duress Codes.
If the Master Code Not Changeable option is enabled the System Master Code can only be changed
using Installer Programming.
How to program Access Codes:
Programming Access Codes is a two step process. First the code must be programmed followed by the
code attributes.
1.Enter [✱] [5] [Master Code]. The keypad will flash the ‘Program’ light and turn on the zone light for any
code already programmed.
2.Enter the 2 digit number for the code you want to program. The corresponding zone light will flash.
3.Enter a four digit code, the zone light will turn on steady.
4.Continue with steps 2 and 3 until all codes are programmed.
Do not press [
✱
] or [#] when programming the access codes.
When programming Duress Codes or Partition Master Codes no zone light will flash.
After all the Codes have been programmed press the [#] key to return to the Ready mode.
How to program Access Code Attributes:
“Master Code” attributes cannot change. By default, each code has the attributes of the code used to
program phone access.
1.Enter [✱][5][Master Code]. The keypad will flash the ‘Program’ light and turn on the zone light for any
code already programmed.
2.Press [9] to enter the Attribute mode. The keypad will turn on the ‘Ready’ light and turn off the armed light.
3.Enter the 2 digit number for the code you want to program Attributes for. Zone lights [1] to [4] will be on
or off. Refer to the following chart:
• Zone Light 1 - ON - enable code for Partition 1 • Zone Light 3 - ON - enable Zone Bypass
• Zone Light 2 - ON - enable code for Partition 2 • Zone Light 4 - ON - enable Escort5580 Access
4.Enter [1] to [4] to turn the zone lights ON or OFF, then press [#] key.
5.Continue with steps 2 and 3 until all code attributes are programmed.
After all the codes and attributes have been programmed press the [#] key to exit Access Code Programming.
