P R O G R A M D E S C R I P T I O N S
25
Swinger Shutdown Enable Determines if the panel will shut down the communicator for the zone after
the swinger limit is reached
(See Section 5.17 “Swinger Shutdown”)
.
Transmission (TX) Delay Enable Determines if the panel will delay communicating the alarm reporting
code to the central station (See Section 5.18 “Transmission Delay”).
Wireless Zone Determines if the zone is a wireless zone or a hardwired zone. Allows the panel to
generate low battery trouble and zone supervisories.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Zones 1 to 32 Attributes ......................................... Section [101] - [132]
Audible/Silent Alarm ............................................... Section [101] - [132], Option [1]
Pulsed/Steady Alarm .............................................. Section [101] - [132], Option [2]
Activate Chime........................................................ Section [101] - [132], Option [3]
Bypass Enable ........................................................ Section [101] - [132], Option [4]
Force Arm Enable ................................................... Section [101] - [132], Option [5]
Swinger Shutdown Enable ..................................... Section [101] - [132], Option [6]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Transmission Delay Enable .................................... Section [101] - [132], Option [7]
5.3 Communicator - Dialing
If the Communicator Disable option is selected the panel will not attempt to call central station. If enabled the
panel will attempt to call central station when an event occurs that has a valid reporting code programmed
(See Section 5.7 “Communicator - Reporting Code”).
You must also program a valid telephone number.
Communicator Call Direction Options are used to select which phone number the panel will dial when
an event occurs.
If DTMF Dialing
is enabled the panel will dial using DTMF (touch tone). If Switch to Pulse Dial is enabled
the panel will switch to pulse dialing on the 5th attempt to call the central station. If disabled the panel will
always dial DTMF.
If DTMF Dialing
is disabled the panel will always pulse dial.
The Post Dial Wait for Handshake
determines the amount of time the panel will wait for a valid
handshake from the receiver. If the panel does not hear the handshake it will consider the call a failed
attempt, hang up and try again.
The Maximum Dialing Attempts determines the maximum number of attempts the panel will make to send a
signal to the central station before indicating a Failure to Communicate (FTC) trouble condition. The 3rd Phone
Number can be used to back up the 1st in this situation
(See Section 5.4 “Communicator - Phone Numbers”).
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Pulse Dialing ........................................................... Section [380], Option [3]
Switch to Pulse Dial................................................ Section [380], Option [4]
Post Dial Wait for Handshake ................................ Section [161]
Maximum Dialing Attempts .................................... Section [160]
Communicator Disable ........................................... Section [380], Option [1]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Communicator Call Direction Options ................... Section [361] to [368]
5.4 Communicator - Phone Numbers
The panel can call 3 different phone numbers for communication to central station. The 1st Phone
Number is the primary number, the 2nd Phone Number is the secondary number and the 3rd Phone
Number will back up the 1st phone number if enabled.
The 3rd Phone Number will NOT back up the 2nd Phone Number.
If
Alternate Dial Alternate Dial
Alternate Dial Alternate Dial
Alternate Dial is enabled the panel will alternate between the 1st and 3rd phone numbers when
attempting to call the central station. If disabled the panel will only attempt to call the 3rd phone number
after failing to communicate on the 1st phone number.
For Alternate Dial to work properly the 3rd Phone Number must be enabled.
Phone numbers can be up to 32 digits which will allow you to add special digits if required. To program
the phone number enter numbers 0 through 9 as required. The following is a list of HEX digits which can
also be programmed and the function they perform:
HEX (B) - simulates the [] key on a touch tone phone HEX (E) - forces the panel to pause for 2 seconds
HEX (C)- simulates the [#] key on a touch tone phone HEX (F) - end of phone number marker
HEX (D)- forces the panel to search for dial tone
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
1st Phone Number.................................................. Section [301]
2nd Phone Number................................................. Section [302]
3rd Phone Number ................................................. Section [303]
3rd Phone Number Enable..................................... Section [380], Option [5]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Alternate Dial .......................................................... Section [380], Option [6]
