SIA Format
Level 2 (Hardcoded)
The SIA communication format used in this product follows the level 2 specifications of the SIA Digital Communica-
tion Standard - January 1996. This format will send the Account Code along with its data transmission. At the
receiver, the transmission would look similar to this example:
N Ri01 BA 01
N = New Event
Ri01 = Partition /Area Identifier
BA = Burglary Alarm
01 = Zone 1
PC5010 Reporting Codes SIA Identifiers &
Auto-Reporting Code
Delay Zone Alarm/Restore ................................. BA-XX / BH-XX*
Instant Zone Alarm/Restore................................ BA-XX / BH-XX*
Interior Zone Alarm/Restore ............................... BA-XX / BH-XX*
Delay S.A. Zone Alarm/Restore ......................... BA-XX / BH-XX *
Interior S.A. Zone Alarm/Restore ....................... BA-XX / BH-XX*
24 Hr Burg Zone Alarm/Restore ......................... BA-XX / BH-XX *
Standard Fire Zone Alarm/Restore ..................... FA-XX / FH-XX*
Delayed Fire Zone Alarm/Restore ....................... FA-XX / FH-XX*
2-Wire Smoke Alarm/Restore ............................... FA-99 / FH-99
24 Hr Supervisory Buzzer Zone Alarm/Restore . UA-XX/ UH-XX*
24 Hr Supervisory Zone Alarm/Restore ............. UA-XX / UH-XX*
24 Hr Medical Zone Alarm/Restore .................. MA-XX / MH-XX*
24 Hr Panic Zone Alarm/Restore ........................ PA-XX / PH-XX *
24 Hr Holdup Zone Alarm/Restore..................... HA-XX / HH-XX*
24 Hr Gas Zone Alarm/Restore ......................... GA-XX / GH-XX*
24 Hr Heat Zone Alarm/Restore ......................... KA-XX / KH-XX*
24 Hr Emergency Zone Alarm/Restore ............. QA-XX / QH-XX *
24 Hr Sprinkler Zone Alarm/Restore ................... SA-XX / SH-XX *
24 Hr Water Zone Alarm/Restore ......................WA-XX / WH-XX *
24 Hr Freeze Zone Alarm/Restore ...................... ZA-XX / ZH-XX *
24 Hr Latching Tamper Alarm/Restore .............. BA-XX / BH-XX*
Duress Alarm ...................................................................... HA-00
Opening After Alarm .......................................................... OR-00
Recent Closing.................................................................... CR-00
Zone Expander Supervisory Alarm/Restore ......... UA-00/UH-00
Keypad Fire Alarm/Restore .................................. FA-00 / FH-00
Keypad Auxiliary Alarm/Restore ........................ MA-00 / MH-00
Keypad Panic Alarm/Restore .............................. PA-00 / PH-00
Audible/Silent 24 Hr ............................................. UA-99 / UH-99
Zone Tamper (1-32) ............................................................ TA-XX *
Appendix B
SIAVFORMAT
PC5010 Reporting Codes SIA Identifiers &
Auto-Reporting Code
Zone Tamper Restorals (1-32) ........................................... TR-XX *
General System Tamper/Restore ......................... TA-00 / TR-00
Keypad Lockout .................................................................. JA-00
Closing By Access Codes 1-32, 33, 34, 40-42 ................. CL-XX◆
Partial Closing .................................................................... CG-XX▼
Special Closing (DLS, Keys, Maint, Quick) ....................... CL-00
Opening By Access Codes 1-32, 33, 34, 40-42 .............. OP-XX◆
Auto-Arm Cancellation........................................................ CE-00
Special Opening (DLS, Keys, Maint) ................................. OP-00
Battery Trouble Alarm/Restore .............................. YT-00/YR-00
AC Failure Trouble Alarm/Restore ........................ AT-00/AR-00
Bell Circuit Trouble Alarm/Restore ........................ UT-99/UJ-99
Fire Trouble Alarm/Restore..................................... FT-00 /FJ-00
Auxiliary Power Supply Trouble Alarm/Restore ...YP-00/ YQ-00
TLM Trouble Code (via LINKS) ...........................................LT-00
General System Trouble/Restore .......................... YX-00 / YZ-00
General System Supervisory/Restore ................... ET-00/ER-00
TLM Restoral ....................................................................... LR-00
FTC Restoral ....................................................................... YK-00
Event Buffer 75% Full Since Last Upload .......................... JL-00
DLS Lead In ........................................................................ RB-00
DLS Lead Out (Successful) ................................................ RS-00
Periodic Test Transmission ................................................ RP-00
System Test......................................................................... RX-00
LINKS1000 Test Transmission ........................................... TX-00
General Transmitter Low Battery/ Restore ............ XT-00/XR-00
General Zone Trouble/Restore .............................. UT-00/UJ-00
Activity/Closing Delinquency ........................................... CD-00
Cross Zone Police............................................................... BV-00
* Zone Number is Identified
◆ User Number is Identified
▼ Each Zone Number is Identified (using UB-XX)
