Programmable Outputs
35
SECTION 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
TLM Only (13)
The output will activate when a telephone line trouble is
present.
TLM and Alarm (14)
The output will activate when a telephone line trouble is
present
and
an alarm occurs on any of the selected partitions.
Failure To Communicate (15)
The output will activate when a Failure to Communicate
trouble is present. The output will stay activated until a suc-
cessful communication is sent to the central station.
Communications Active (16)
The output will activate while the panel is attempting to
communicate with the central station.
Ground Start (17)
The output will activate for a programmable number of sec-
onds before the panel attempts to communicate with the cen-
tral station.
NOTE: This output will follow the ’Ground Start’ PGM pulse
time (see 11.4 ‘Output Pulse Times‘). This output must not
be used on UL Listed systems.
Kissoff Output (18)
The output will activate for a programmed number of sec-
onds after a successful communication to the central station.
NOTE: This output will follow the ’Kissoff Pulse’ PGM pulse
time (see 11.4 ‘Output Pulse Times‘).
Combus Power (19)
This output will deactivate when a Combus reset is per-
formed by the panel.
Ready Status (20)
The output will activate when all the selected partitions are
ready to be armed. If any of the selected partitions are not
ready, the output will deactivate.
Zone Alarm (21)
This output will annunciate when a selected zone has gone
into alarm. Any zone can be selected. If the zone goes into
alarm, the output will activate. The output will remain active
until the partition is armed again.
Zone Follow (22)
This output will follow a selected zone. Any zone can be
selected. If the zone is opened, the output will activate. When
the zone is secured, the output will deactivate. When the Fol-
Fol-Fol-
Fol-
lows + Alarms
lows + Alarmslows + Alarms
lows + Alarms system toggle option is enabled, the output
will remain active until the partition that the zone belongs to
is armed or disarmed (ref #[000200]).
Duress (23)
This output will activate when a Duress code is used to per-
form any function.
NOTE: This output will follow the Duress pulse timer (see
11.4 ‘Output Pulse Times‘).
Buzzer Follow (24)
This output will activate when any of the following events
occur on the selected partitions:
•entry delay faults
• auto-arm pre-alert 24Hr quick bypass pre-alert
• 24HR buzzer zone alarm AML supervisory faults
• tampers fire supervisory alarms
Remote Operation (25)
This option can be activated remotely using downloading,
and will remain active until deactivated by the downloading
computer.
Exit Follow (26)
This option will follow the exit delay for the selected parti-
tion(s).
Entry Follow (27)
This output will follow the entry delay for the selected parti-
tion(s).
Zone Tamper (28)
This output will activate when any zone tamper alarm
occurs on the selected partitions. It will remain active until
the partition is disarmed (alarm silenced) or the bell time-out
is reached.
Zone Fault (29)
This output will activate when any zone fault alarm occurs
on the selected partitions. It will remain active until the parti-
tion is disarmed (alarm silenced) or the bell time-out is
reached.
Zone Tamper Follow (30)
This output will indicate when a zone goes into a tamper
alarm. Any zone can be selected. If the zone is tampered, the
output will activate; when the zone is restored, the output
will deactivate. When the Follows + Alarms
Follows + AlarmsFollows + Alarms
Follows + Alarms system toggle
option is enabled, the output will remain active until the par-
tition that the zone belongs to is armed (ref #[000200]).
Zone Fault Follow (31)
This output will indicate when a zone goes into a fault alarm.
Any zone can be selected. If the zone is faulted, the output
will activate; when the zone is restored, the output will deac-
tivate. When the Follows + Alarms
Follows + AlarmsFollows + Alarms
Follows + Alarms system toggle option is
enabled, the output will remain active until the partition that
the zone belongs to is armed (ref #[000200]).
Armed Stay Mode (32)
This output will activate when a selected partition is armed
in the Stay mode (i.e. when the partition is armed with Stay/
Away zones bypassed).
Armed Away Mode (33)
This output will activate when a selected partition is armed
in the Away mode (i.e. when all Stay/Away zones are
active).
2-wire Smoke Alarm (34)
The output will follow the alarm status on the PC4701 2-wire
smoke input, if installed. If the input is in alarm, the output
will activate; when the alarm is restored, the output will
deactivate.
2-wire Smoke Trouble (35)
The output will follow the trouble status on the PC4701 2-
wire smoke input, if installed. If the input exhibits a trouble,
the output will activate; when the trouble is restored, the out-
put will deactivate.
Waterflow Alarm (36)
The output will follow the alarm status on the PC4701 Water-
flow input, if installed. If the input is in alarm, the output will
activate; when the alarm is restored, the output will deacti-
vate.
Waterflow Trouble (37)
The output will follow the trouble status on the PC4701
Waterflow input, if installed. If the input exhibits a trouble,
the output will activate; when the trouble is restored, the out-
put will deactivate.
Command Outputs 1-8 (38-45)
The output will activate when the corresponding [*] [7] [1-
8] command is entered on the selected partition. Enter a
pulse time for each output (default = 000 seconds; 005 sec-
onds for Command Output #2). A pulse time of [000] will
allow the output to be toggled on and off using the corre-
sponding [*] [7] [1-8] command.
NOTE: All command outputs will deactivate when you exit
installer’s mode.
