057-001 720 Operating Instructions Issue 3.1 20/12/2005 AM - 15 -
Parameter Minimum Maximum Default
Misc
31 - Full Load Current Rating 5A 6000A 500A
32 - Current Transformer Primary 5A 6000A 500A
33 - Alternator Poles 2 8 4
34 - AC Topology (see note 1) 0 1 0
Possible selections : 0 - 3 phase, 4 wire
1 - Single phase, 2 wire
35 - Oil Pressure Display Units 0 1 0
Possible selections : 0 - Bar / PSI
1 - Kpa
36 - Oil pressure sender type 0 - Not used
1 - Digital closed for low oil pressure
2 - Digital open for low oil pressure
3 - VDO 5 bar
4 - VDO 10 bar
5 - Datcon 5 bar
6 - Datcon 10 bar
7 - Datcon 7 bar
8 - Murphy 7 bar
9 - User configured
37 - Coolant temperature sender type 0 – Not used
1 - Digital closed for high temperature
2 - Digital open for high temperature
3 - VDO 120 ° C
4 - Datcon high
5 - Datcon low
6 - Murphy
7 - Cummins
8 - PT100
9 - User configured
Mains
38 - Immediate Mains Dropout 0 1 1
Possible selections : 0 - No
1 - Yes
39 - Mains Undervolt Trip 50V 333V 184V
40 - Mains Undervolt Return 50V 333V 207V
41- Mains Overvolt Return 50V 333V 253V
42 - Mains Overvolt Trip 50V 333V 276V
43 - Mains transient Delay 0 sec 30 sec 0 sec
