057-001 720 Operating Instructions Issue 3.1 20/12/2005 AM - 19 -
6.1.2 CONNECTOR B
PIN
No
DESCRIPTION CABLE SIZE NOTES
14 Remote Start / Simulated Mains
input
0.5mm
2
(20 AWG) Requires a contact to plant supply
negative.
15 Configurable input 1 0.5mm
2
(20 AWG) Requires a contact to plant supply
negative.
16 Configurable input 2 0.5mm
2
(20 AWG) Requires a contact to plant supply
negative.
17 Functional Earth 2.5mm
2
(13 AWG) Connect to a good, clean Earth point
18 Generator Current L1 i/p 2.5mm
2
(18 AWG) Connect to Gen L1 CT
19 Generator Current L2 i/p 2.5mm
2
(18 AWG) Connect to Gen L2 CT
20 Generator Current L3 i/p 2.5mm
2
(18 AWG) Connect to Gen L3 CT
21 Generator Current Common i/p 2.5mm
2
(18 AWG) Connect to Gen CT common
NOTE:- Remote Start / Simulated Mains function is configurable using either the front
panel configuration editor or the 72x PC configuration software.
NOTE:- Current inputs are rated at 5A maximum. If it is required to measure overload,
then the CT should be sized to cater for this. Ie for 100A set, fit 120A:5A CTs to allow the
module to measure 20% overload without exceeding the module’s 5A specification.
6.1.3 CONNECTOR C
PIN
No
DESCRIPTION CABLE SIZE NOTES
22 Mains(Utility)voltage L1 i/p 1.0mm
2
(18 AWG) Connect to Mains L1
23 Mains(Utility)voltage L2 i/p 1.0mm
2
(18 AWG) Connect to Mains L2
24 Mains(Utility)voltage L3 i/p 1.0mm
2
(18 AWG) Connect to Mains L3
25 Mains(Utility)voltage Neutral i/p 1.0mm
2
(18 AWG) Connect to Mains Neutral
26 Generator voltage L1 i/p 1.0mm
2
(18 AWG) Connect to Generator L1 output
27 Generator voltage Neutral i/p 1.0mm
2
(18 AWG) Connect Generator Neutral
6.2 ORDERING REPLACEMENT CONNECTORS FROM DSE
Connector Description DSE Part No.
A (1-13) BL13 PCB connector 5.08mm plug 007-104
B (14-22) BL08 PCB connector 5.08mm plug 007-125
C (23-27) BL06 PCB connector 7.62mm plug 007-432
