9 FAULT FINDING
SYMPTOM POSSIBLE REMEDY
Unit is inoperative Check the battery and wiring to the unit. Check the DC supply. Check the DC fuse.
Unit shuts down Check DC supply voltage is not above 35 Volts or below 9 Volts
Check the operating temperature is not above 70 °C. Check the DC fuse.
Low oil Pressure fault operates after
engine has fired
Check engine oil pressure. Check oil pressure switch and wiring. Check switch
polarity is correct (i.e. Normally Open or Normally Closed).
High engine temperature fault
operates after engine has fired.
Check engine temperature. Check switch and wiring. Check switch polarity is
correct (i.e. Normally Open or Normally Closed).
Shutdown fault operates Check relevant switch and wiring of fault indicated by the illuminated LED. Check
configuration of input.
Warning fault operates Check relevant switch and wiring of fault indicated by the illuminated LED. Check
configuration of input.
Fail to Start is activated after pre-set
number of attempts to start
Check wiring of fuel solenoid. Check fuel. Check battery supply. Check battery
supply is present on the Fuel output of the module. Refer to engine manual.
Continuous starting of generator
when in AUTO
Check that mains (utility) supply is healthy and check that it’s protection fuses are in
place and are not blown.
Check that there is no signal present on the “Remote Start” input.
Generator fails to start on receipt of
Remote Start signal or mains (utility)
supply failure.
If remote start fault, check signal is on “Remote Start” input. Confirm that the input
is configured to be used as “Remote Start”.
Pre-heat inoperative Check wiring to engine heater plugs. Check battery supply. Check battery supply is
present on the Pre-heat output of module. Check pre-heat has been selected in
your configuration.
Starter motor inoperative Check wiring to starter solenoid. Check battery supply. Check battery supply is
present on the Starter output of module. NB all the outputs are negative switching.
Fuel solenoid inoperative Check wiring to fuel solenoid. Check battery supply. Check battery supply is present
on the fuel output of module. NB all the outputs are negative switching.
Engine runs but generator will not
take load
Check that the output is working, NB all outputs are negative switching.
NOTE:- The above fault finding is provided as a guide check-list only. As it is possible
for the module to be configured to provide a wide range of different features always refer
to the source of your module configuration if in doubt.
NOTE:- All the outputs are solid state and switch to battery positive when active.
