- 20 - 057-001 720 Operating Instructions Issue 3.1 20/12/2005 AM
7 SPECIFICATION
DC Supply 8.0V to 35V Continuous.
Cranking Dropouts Able to survive 0V for 50mS, providing supply was at least 10V before
dropout and supply recovers to 5V. This is achieved without the need
for internal batteries.
Typical Standby Current 145mA at 12V. 150mA at 24V
Max. Operating Current 180mA at 12V. 190mA at 24V
Alternator / Mains (Utility) Input
Range
Single phase 2 wire system 35V AC - 277V AC (ph-N) (+20%)
3Phase 4Wire System 35V AC - 277V AC (ph-N) 3 Phase 4wire (+20%)
(Must be at least 15V during engine cranking)
Alternator / Mains (Utility) Input
Frequency
50Hz - 60 Hz at rated engine speed
Start Output 2.4 Amp DC at supply voltage.
Fuel Output 2.4 Amp DC at supply voltage.
Auxiliary Outputs 1.2 Amp DC at supply voltage.
Dimensions 209mm x 146mm (8.23” x 5.75”)
Panel cut-out 182mm x 137mm (7.17” x 5.39”)
Maximum panel thickness – 8mm (0.3”)
Charge Fail / Excitation Range 12 Volts nominal = 8 Volts Charge fail
24 Volts nominal = 16 Volts Charge fail
Current Transformer Specification 5A 0.5VA secondary winding
Operating Temperature Range -30°C to +70°C
Electromagnetic Compatibility BS EN 50081-2 EMC Generic Emission Standard (Industrial)
BS EN 50082-2 EMC Generic Immunity Standard (Industrial)
Electrical Safety BS EN 60950 Safety of I.T. equipment, including electrical business
equipment.
Cold Temperature
BS EN 60068-2-1 to –30°C
Hot Temperature
BS EN 60068-2-2 to +70°C
Humidity
BS2011-2-1 to 93% RH @ 40°C for 48 Hours
Vibration BS EN60068-2-6
10 sweeps at 1 octave/minute in each of 3 major axes.
5Hz to 8Hz @ +/-7.5mm constant displacement
8Hz to 500Hz @ 2gn constant acceleration
Shock BS EN 60068-2-27
3 Half sine shocks in each of 3 major axes
15gn amplitude, 11mS duration
Applicable Standards
Compliant with BS EN 60950 Low Voltage Directive
Compliant with BS EN 50081-2: 1992 EMC Directive
Compliant with BS EN 61000-6-4: 2000 EMC Directive
Compliance to European Legislation
