057-001 720 Operating Instructions Issue 3.1 20/12/2005 AM - 9 -
3.4 PROTECTIONS
The module will indicate that an alarm has occurred by illuminating the relevant LED.
3.5 WARNINGS
Warnings are used to warn the operator of an impending fault but the engine continues to run.
BATTERY CHARGE FAILURE, if the module does not detect a voltage from the warning light
terminal on the auxiliary charge alternator, the icon will illuminate. (Either 8 Volts or 16 Volts
depending on the configuration of Nominal DC Voltage).
LOW PLANT BATTERY ALARM The module’s DC supply is monitored and if it falls below the
configurable level an alarm is generated and the
icon will illuminate.
INPUTS 1 AND 2 can be configured as warnings or shutdowns. The relevant icon will be
illuminated when the input is active.
The item is indication only (not an alarm). For instance this could indicate “System in Auto”
The item has generated a Warning alarm condition.
