DSE
®
' '%#$&'"!
COMPREHENSIVE FEATURE LIST TO SUIT A WIDE VARIETY OF
BATTERY CHARGER APPLICATIONS
DSE9460/9461
ENCLOSED INTELLIGENT BATTERY CHARGER
5 AMP & 10 AMP, 12 VOLT & 24 VOLT OPTIONS
The DSE94xx series of metal
enclosed intelligent battery chargers
have been developed with safety,
usability, optimised battery
performance and maximum battery
lifetimes in mind.
The DSE94xx series can be used
directly from the box, relying on a
preconfigured lead/acid charging
curve and selected manually for
either 12V or 24V operation
(including a voltage trimming
potentiometer function). Alternatively
they can be connected via a USB to
a PC (using the free DSE PC
configuration suite software) and can
be configured with pre set charging
curves for different battery types.
The user also has the option of
configuring their own bespoke
charging curve for advanced battery
applications.
A comprehensive range of input and
output protections ensures a
continued safe charging
environment also enabling the use of
the charger as a power supply.
Higher charging / power supply
currents can be achieved by linking
together multiple chargers from this
series.
The chargers can be integrated into
an external system through modbus
RTU using RS485 as well as an
optional external remote LCD
display being available.
FEATURES
ENVIRONMENTAL TESTING STANDARDS
ELECTRO-MAGNETIC COMPATIBILITY
BS EN 61000-6-2
EMC Generic Immunity Standard for
the Industrial Environment
BS EN 61000-6-4
EMC Generic Emission Standard for
t
he Industrial Environment
TEMPERATURE
BS EN 60068-2-1
Ab/Ae Cold Test -30
o
C
BS EN 60068-2-2
Bb/Be Dry Heat +80
o
C
*
Refer to de-rating curve in the DSE9000
Operator Manual
VIBRATION
BS EN 60068-2-6
Ten sweeps in each of three
major axes
5
Hz to 8 Hz at +/-7.5 mm,
8 Hz to 500 Hz at 2 gn
HUMIDITY
BS EN 60068-2-30
D
b Damp Heat Cyclic 20/55
o
C
a
t 95% RH 48 Hours
B
S EN 60068-2-78
C
ab Damp Heat Static 40
o
C
at 93% RH 48 Hours
S
HOCK
B
S EN 60068-2-27
Three shocks in each of three major axes
15 gn in 11 mS
ISSUE 1
CHARGE OUTPUT
AC POWER SUPPLY
CONFIGURABLE INPUT
RS485
AUXILIARY DC OUTPUT
USB PORT
DSE9460/DSE9461
TEMPERATURE SENSOR
PT1000 ONLY
CHANGE OVER VOLTS FREE FAULT
RELAY
1
1
12V
1ph
N
9461-01
9461-02
9461-03
9461-04
9
461-11
9461-12
9461-13
9461-14
12v 10A (LCD)
1
2v 10A (LCD & Meters)
1
2v 10A (LED & Meters)
12v 10A (LED)
24v 10A (LCD)
24v 10A (LCD & Meters)
24v 10A (LED & Meters)
2
4v 10A (LED)
AVAILABLE 10 AMP VERSIONS
9460-01
9460-02
9
460-11
9460-12
12v 5A (LCD)
12v 5A (LCD & Meters)
2
4v 5A (LCD)
24v 5A (LCD & Meters)
AVAILABLE 5 AMP VERSIONS
'%#$&
+
