KEY BENEFITS
• Fully flexible to maximise the life of the battery
• Suitable for a wide range of battery types
• Switched mode design
• Fault output
• Minimum 86% efficiency throughout full
operating range
• No external intervention for boost mode
• Multiple chargers can be linked together to
provide larger current output
• Can be permanently connected to battery and
mains (utility) supply. No need to disconnect
through high load conditions.
ADVANCED FEATURES
• Intelligent two, three and four stage charging
profiles
• Configurable to suit most battery types
(12V/24V)
• Adjustable current limit
• Can be used as a battery charger, power supply
or both at the same time
• Automatic or Manual boost and storage charge
functions to help maintain battery condition
• Digital Microprocessor Technology
• Temperature compensation for battery charging
• Low Output Ripple and superb line regulation
• Available in two variants (LCD display or LCD
display & analogue meters)
• AC input Under voltage
• AC input Over voltage
• Battery charger output Over voltage
• Battery charger output Over current
• Battery temperature compensation with over
temperature protection
• Output short circuit and Inversion polarity with
auto recovery
• Automatic power de-rating at high ambient
temperatures
• Battery charger failure indication
•
Boosts and equalises cell charge improving
battery performance and life
•
Once the battery is fully charged the chargers
switch to Eco-Power to save energy
• Can be integrated into external systems through
MODBUS RTU using RS485
• Fully configurable via DSE Configuration Suite
PC Software
• External remote LCD option
RELATED MATERIALS
TITLE PART NO’S
DSE9000 Configuration Suite PC Software Manual 057-159
DSE Configuration Suite Installation & Operator Manual 057-151
DSE9460/DSE9461 Series Installation Instructions 053-148
DSE9460/DSE9461 Series Operator Manual 057-176
DSE2541 Data Sheet 055-160
DSE2541 Installation Instructions 053-154
DSE9460/9461
ENCLOSED INTELLIGENT BATTERY CHARGER
5 AMP & 10 AMP, 12 VOLT & 24 VOLT OPTIONS
FEATURES
Registered in England & Wales No.01319649
VAT No.316923457
Deep Sea Electronics Plc maintains a policy of continuous development and reserves the right to change
the details shown on this data sheet without prior notice. The contents are intended for guidance only.
SPECIFICATION
AC SUPPLY
VOLTAGE RANGE
90 V to 305 V (L-N)
FREQUENCY RANGE
48 Hz to 64 Hz (L-N)
DC OUTPUT RATING
DSE9460 OUTPUT
5 A DC at 12 V & 24 V DC
DSE9461 OUTPUT
10 A DC at 12 V & 24 V DC
RIPPLE AND NOISE
<1%
EFFICIENCY
>86%
AUXILIARY OUTPUT
100 mA DC at 12 V
REGULATION
LINE
<0.5%
LOAD
2%
TEMPERATURE SENSOR INPUT
PT1000
PROTECTIONS
Short Circuit
DC Over Voltage
D
C Over Current
Reverse Polarity
Over Temperature
AC Under & Over Voltage
Battery Charger Failure
CHARGE FAILURE RELAY
3 A at 30 V DC volt free relay
DIMENSIONS
OVERALL
165 mm x 305 mm x 110 mm
6.5” x 12” x 4.3”
WEIGHT
2.3 kg
OPERATING TEMPERATURE RANGE
-30
o
C to +55
o
C
STORAGE TEMPERATURE RANGE
-40
o
C to +85
o
C
