Key-On/Key-Off using the button on the Hands
free lock with the passive key
Key-On can be performed by pressing button (7) on
the Hands free lock and with the presence of the
passive key (4, Fig. 87).
Note
The passive key has a range of a few cm,
therefore the key must be positioned near the
antenna. Remove the seat to reach the antenna.
Key-Off can be performed by pressing button (7) on
the Hands free lock (1, Fig. 87), also without the key
(4, Fig. 87).
7
Fig. 95
2
Fig. 96
