MAIN COMPONENTS AND DEVICES
Location (fig. 26)
1) Tank filler plug.
2) Passenger seat lock and helmet holder.
3) Side stand.
4) Rear shock absorber adjusters.
5) Rear-view mirrors.
6) Silencer and exhausts.
7) Catalytic converter (not on USA version).
Warning
The exhaust system might be hot, even after engine
is switched off; take special care not to touch exhaust
system with any body part and do not park the motorcycle
next to inflammable material (wood, leaves etc.).
fig. 26
3
4
6
7
6
6
2
5
5
1
