Electrical system
Basic electric items are:
front headlamp featuring two halogen lamps, consisting
of the following:
HB3 12V-60W low beam unit;
HB3 12V-60W high beam unit;
12V-5W parking light.
Electrical controls on handlebars.
Turn indicators, 12V-10W bulbs.
Horn
Stop light switches.
Sealed battery, 12V-10 Ah.
Generator 12V-520W.
Electronic voltage regulator (rectifier), protected by a
40 A fuse near the battery.
DENSO starter motor, 12V-0.7 kW.
Tail light, 12V-5/21W double filament bulb for stop light
and parking light; 12V-5W bulb for number plate light.
Notes
To replace the bulbs, see “Replacing bulbs” on page 64.
