Movable fairing
Unscrew the four screws (1) securing the movable
fairing to the brackets with the seal (2).
Remove the movable fairing complete with the
windshield (fig. 40).
To replace the windshield, use the special torx wrench
to unscrew the screws (3) and nylon washers (4), while
holding the rubber coated nuts (5) in position from the
inside of the fairing (fig. 40a).
When fitting the new windshield, tighten the screws (2)
starting with the central screw.
Make sure that the seals (2) are correctly fitted to the
brackets, then fit the movable fairing and secure it with
the screws (1).
Tighten the screws (1).
3
4
5
fig. 40a
1
2
fig. 40
