Before refitting the side fairing, make sure that the
grommets (3) and seal (4) are correctly fitted over the pin
(5) on the inside of the side fairing (fig. 44).
Fit the left side fairing, starting from the rear, engaging
the tank pins in the grommets (fig. 44a).
Push on the side fairing at the pin (5) to engage the stop
(2) over the end of the pin.
Engage the front quick release (1), pushing it in and
turning it ¼ of a turn clockwise.
Panniers
The motorcycle has provision for fitting side panniers.
The pannier kit is available from the Ducati spare parts
service.
As well as all the parts necessary for fitting, the kit also
contains an instruction booklet.
34
5
fig. 44
fig. 44a
