E
71
Unscrew the two self-tapping screws (3) securing the
shell (4) and number plate lens.
Remove the shell and lens and change the number plate
bulb (5) (fig. 66).
To change the brake light bulb proceed as instructed above
and also remove the brake light lens (6) from its mounting.
Push and twist the bulb (7) anti-clockwise to change it
(fig. 67).
When refitting the lens (6) make sure that the tabs (B)
engage the slots in the mounting correctly.
4
5
4
3
fig. 66
6 7
B
fig. 67
