E
89
Remove the protective cap (A, fig. 78) to expose the fuses.
A blown fuse is identified by the interrupted inner filament
(5, fig. 79).
Important
Switch the ignition key to OFF before replacing the
fuse to avoid possible short circuits.
Warning
Never use a fuse with a rating other than specified.
Failure to observe this rule may damage the electric
system or even lead to fire.
A 2
fig. 78
5 5
IN GOOD CONDITION BLOWN
fig. 79
