Charging the
Before charging the it is best to remove it
from the motorcycle.
Removing the
●
Remove the side fairing;
●
undo the screw (1) and remove the
mounting cover (2).
●
remove (3) from its seat;
●
always from the negative terminal (-),
loosen the screws (4).
●
remove the negative cable (7) and engine
ground cable (8) from the negative terminal;
●
remove the positive cable (5) and ABS positive
cable (6) from the positive terminal.
Fig 148
Fig 149
177
