Ducati PANIGALE - Aligning the Headlight

Aligning the headlight
Check correct headlight aiming. Position the
motorcycle 10 m (32.8  from a wall or a screen, the
motorcycle must be  upright with the Tyres
inflated to the correct pressure and with a rider
seated,  perpendicular to the longitudinal
axis. On the wall or  draw a horizontal line at
the same height from the ground as the centre of
the headlight and a  line aligned with the
longitudinal axis of the motorcycle. If possible,
 this check in dim light. Switch on the low
beam and adjust right and  beams. The height of
the upper limit between the dark area and the lit area
must not be more than 9/10 of the height from the
ground of the headlight centre.
10 m
9
10
x
x
Fig 162
189
