Engine rpm indication
The engine rpm is displayed using a rev counter
featuring a coloured wake: grey in DAY mode and
white in NIGHT mode
When the wake becomes amber yellow, the
instrument panel is warning the rider to up.
The red wake flashes when the limiter kicks in and
the Over-rev warning lights (12 and 13, Fig 40) turn
on.
If the number of rpm is lower than 1,000 RPM, the
wake is not displayed.
DQS
EBC
1
3
2
3
4
5
6
7
8
9
11
10
12
12:34
PM
DTC
DDA OFF
3
3
U/D
ABS 1
DWCRPM X 1000
km/h
TOT
120 °C
SPORT
Gear
1
km
260
90
Fig 43
78
