Front  fuse box (A) key
Pos El. item Rat.
1 EMS/ABS/IMU 5 A
2 DASH/BBS/SMEC 7.5 A
3 - -
4 Accessories (SW) 5 A
5 Injection relay 20 A
6 Diagnostics/
Recharge
7.5 A
7 Spare 5 A
8 Spare 15 A
9 Spare 20 A
Front right fuse box (B) key
Pos El. item Rat.
1 ABS 1 25 A
2 ABS 2 10 A
3 Instrument panel 15 A
4 Black Box System
(BBS)
10 A
Front right fuse box (B) key
5 Fuel pump relay 10 A
6 EMS powered relays 25 A
7 Spare 15 A
8 Spare 10A
9 Spare 25 A
