19
Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
Proofer Drip Channel Reversal:
The proofer door has a sloped drip channel on the bottom that directs any water that drips down the
door into the water pan below the door. When the door swing is reversed this drip channel must be
replaced with a new channel that has the slope in the proper direction. Contact Duke Manufacturing
Service for a new drip channel before changing door swing direction.
Figure 32: Right Hinge Drip Channel Slope Towards Right
Figure 33: Left Hinge Drip Channel Slope Towards Left
