Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
• This unit is not to be operated by children, unskilled or untrained persons, or persons with insufcient
mental or physical capabilities.
• Turn off external mains supply disconnect and allow unit to cool down before servicing or performing
maintenance.
• The procedures in this manual may include the use of chemical products. You must read the Material
Safety Data Sheets before using any of these products.
• Properly rated all poles mains protection and earthing compliance with local electric codes are required
for safe operation of this unit.
• Water supply connections to the unit must comply with local plumbing code and/or standards.
• Disposal of the unit must be in accordance with local environmental codes and/or any other applicable
codes.
Lamp(s) inside the LCD display in this product contain mercury and must be recycled or •
disposed of according to local, state or federal laws.
• SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS (continued)
Hg
Technical Description and Application Notes for TSC Proofer Oven Backow Preventer Assembly
This equipment is intended to be connected to a
potable water supply system under pressure and is
to be installed with adequate backflow protection
to comply with all applicable federal, state, and
local codes.
Water supply pressure for proper operation shall be:
Minimum 40 PSIG(275 KPa)
Maximum 65 PSIG(448 KPa)
measured at water line inlet to the equipment.
If so equipped, regular maintenance is required to
replace the water filter cartridge at least once per
year, and to clean the inlet water screen at least
once per year. Consult state/local codes for any
additional requirements.
INSTALLATION OF WATER FILTER
Install new filter by removing sanitary cap from top
of cartridge, insure two black O-rings are in place,
then lift up into filter head and rotate cartridge
1/4 turn counter clockwise until it comes to a complete
stop. Flush 2 gallons (5.6 Liters) of water through the
new filter before using proofer to purge air from filter.
Remove hose from bottom of proofer by loosening
the compression nut at the disconnect fitting
and pull hose out. Place hose over container and
turn on water. It will take a minute for the filter
to fill before water flows out of hose into container.
once filter is flushed with 2 gallons (5.6 Liters) of water,
turn off water supply again, insert hose into water line
disconnect, tighten compression nut and turn
water supply on again. Check for leaks at
connection fittings.
Patent(s) Pending
Check with your local authority having jurisdiction
regarding approvals for connecting the Duke TSC
Proofer Oven to a potable water supply before
making any plumbing connections. Plumbing
code requirements vary, but Duke has made a kit
(P/N 600187) available (or installed as a factory
option) to add a backow prevention device to
protect water supply systems by preventing the
reverse ow of non-potable water into the potable
domestic water system. The device consists of
two independently acting check valves, internally
force-loaded to a normally closed position
and designed/constructed to operate under
intermittent or continuous pressure conditions.
The two main components of the Duke backow
preventer system are:
Dual Check Valve type backow preventer •
that conforms to ANSI/ASSE standard #1024
and is CSA standard B64.6 certied.
Inlet water strainer equipped with 100-mesh •
screen and installed up stream of the backow
preventer. The screen is conveniently located
on the rear panel of the proofer, below the
backow preventer, for easy access during
cleaning/replacement.
