Dungs MPA22 User Manual

Printed in Germany / M-MT-BOS
• Edition11.99 • # 231 763
107 … 112
Display in parameteriza-
tion mode
Gas firing, electronic
modulation
Gas firing, pneumatic
modulation
Oil firing, three stage
Specify control address of system.
The following addresses are possible:
10H, 17H, 30H, 37H, 70H, 77H, F0H,
F7H
The changed address is not stored
until you advance the program or exit
parameterisation mode via timeout.
P
S
i
G
L/A
h
l,m
3
Timeout
approx. 20 s
Timeout
approx. 20 s
P
S
i
G
L/A
h
l,m
3
approx. 0.2 s
7
+
–
Back to operating
display
