- 20 -
2.0 INSTALLATION
POINT LOAD LOCATION
MODEL
ACDS
DIMENSIONS – INCH [MM]
A B C D E F
030 84 [2134] 16 [406] 76 [1930] 16 [406] - -
040 84 [2134] 16 [406] 76 [1930] 16 [406] - -
050 84 [2134] 20 [508] 102 [2600] 20 [508] - -
060 84 [2134] 20 [508] 102 [2600] 20 [508] - -
070 84 [2134] 20 [508] 102 [2600] 20 [508] - -
080 84 [2134] 12 [305] 58[1467] 66 [1675] 12 [305] -
090 84 [2134] 12 [305] 58[1467] 66 [1675] 12 [305] -
100 84 [2134] 16 [406] 86 [2172] 71 [1803] 16 [406] -
120 84 [2134] 16 [406] 86 [2172] 71 [1803] 16 [406] -
135 84 [2134] 30 [762] 83 [2102] 83 [2102] 30 [762] -
150 84 [2134] 30 [762] 83 [2102] 83 [2102] 30 [762] -
165 84 [2134] 30 [762] 69 [1757] 69 [1757] 69 [1757] 30 [762]
180 84 [2134] 30 [762] 69 [1757] 69 [1757] 69 [1757] 30 [762]
POINT LOAD DATA
MODEL
ACDS
LOADS - LBS [KG] TOTAL
OPERATING
WEIGHT
LBS [KG]
P1 P2 P3 P4 P5 P6 P7 P8
030 470 [213] 713 [323] 713 [323] 470 [213] - - - - 2365 [1073]
040 611 [277] 704 [319] 704 [319] 611 [277] - - - - 2629 [1193]
050 1060 [481] 932 [423] 932 [423] 1060 [481] - - - - 3984 [1807]
060 1133 [514] 963 [437] 963 [437] 1133 [514] - - - - 4193 [1902]
070 1207 [548] 998 [452] 998 [452] 1207 [548] - - - - 4409 [2000]
080 836 [379] 819[372] 804[365] 804[365] 819[372] 836 [379] - - 4918 [2231]
090 904 [410] 881 [400] 860 [390] 860 [390] 881 [400] 904 [410] - - 5290 [2400]
100 1026 [465] 1043 [473] 1064 [482] 1064 [482] 1043 [473] 1026 [465] - - 6264 [2841]
120 1049 [476] 1063 [482] 1080 [490] 1080 [490] 1063 [482] 1049 [476] - - 6383 [2865]
135 1137 [516] 1242 [564] 1348 [611] 1348 [611] 1242 [564] 1137 [516] - - 7454 [3381]
150 1225 [556] 1334 [605] 1443 [655] 1443 [655] 1334 [605] 1225 [556] - - 8005 [3631]
165 1110 [504] 1141 [518] 1172 [532] 1202 [545] 1202 [545] 1172 [532] 1141 [518] 1110 [504] 9251 [4196]
180 1225 [556] 1242 [564] 1260 [571 1277 [579] 1277 [579] 1260 [571] 1242 [564] 1225 [556] 10007 [4539]
