4.0 ELECTRICAL
4.1 ELECTRICAL DATA
MODEL
Power Supply Standard Unit Electrical Data Each Compressor Condenser Fan Motors
V-Ph-Hz RLA MCA MFS/HACR Qty RLA LRA-XL Qty HP FLA/Mtr
ACDS-010
208/230-3-60 61 68 90 2 27 145 1 2 7.2
460-3-60 27 30 40 2 12 87 1 2 3.4
ACDS-020
208/230-3-60 103 114 150 2 46 304 2 1.5 5.4
460-3-60 47 53 70 2 21 147 2 1.5 2.7
ACDS-030
208/230-3-60 134 148 200 2 56 320 4 1.5 5.4
460-3-60 63 69 90 2 26 160 4 1.5 2.7
ACDS-040
208/230-3-60 206 217 250 4 46 304 4 1.5 5.4
460-3-60 95 100 110 4 21 147 4 1.5 2.7
ACDS-050
208/230-3-60 256 270 300 4 56 320 6 1.5 5.4
460-3-60 120 127 150 4 26 160 6 1.5 2.7
ACDS-060
208/230-3-60 294 313 350
2
2
56
75
320
485
6 1.5 5.4
460-3-60 140 149 175
2
2
26
36
160
215
6 1.5 2.7
ACDS-070
208/230-3-60 332 351 400 4 75 485 6 1.5 5.4
460-3-60 160 169 200 4 36 215 6 1.5 2.7
ACDS-080
208/230-3-60 381 405 450
2
2
75
94
485
560
6 2 7.2
460-3-60 184 196 225
2
2
36
46
215
260
6 2 3.4
ACDS-090
208/230-3-60 419 443 500 4 94 560 6 2 7.2
460-3-60 204 216 250 4 46 260 6 2 3.4
ACDS-100
208/230-3-60 486 516 600
2
2
94
120
560
680
8 2 7.2
460-3-60 231 245 300
2
2
46
56
260
320
8 2 3.4
ACDS-120
208/230-3-60 538 568 600 4 120 680 8 2 7.2
460-3-60 251 265 300 4 56 320 8 2 3.4
ACDS-135
208/230-3-60 579 603 700
3
3
75
94
485
560
10 2 7.2
460-3-60 280 292 300
3
3
36
46
215
260
10 2 3.4
ACDS-150
208/230-3-60 636 660 700 6 94 560 10 2 7.2
460-3-60 310 322 350 6 46 260 10 2 3.4
ACDS-165
208/230-3-60 728 758 800
3
3
94
120
560
680
12 2 7.2
460-3-60 347 361 400
3
3
46
56
260
320
12 2 3.4
ACDS-180
208/230-3-60 806 836 900 6 120 680 12 2 7.2
460-3-60 377 391 400 6 56 320 12 2 3.4
Note: MCA - Minimum Circuit Ampacity MFS - Maximum Fuse Size RLA - Running Load Amps
FLA – Full Load Amps LRA - Locked Rotor Amps
