33
7. FINE-ADJUSTING PAPER ALIGNMENT, STAPLING AND FOLDING POSITIONS
e Press the center of the jog dial to confirm the selected value.
r Perform steps 4 to 6 in order to check the binding condition.
While referring to the figures in “7-1. Check the Binding Condition”, check the ejected paper in the following order.
w Press the center of the jog dial to enter the value selection mode, then turn the jog dial to select the adjustment value (–9
to 9).
Align the folding line with the stapling position.
The value for “1” is approximately 0.5 mm (0.02").
Check the following cases, referring to the figures in “7-1. Check the Binding Condition”.
If the folded line is 2 mm (0.08") above the stapled position, select “4” (2 ÷ 0.5).
Adjust Fold
4
If the folded line is 1 mm (0.04") below the stapled position, select “–2” (–1 ÷ 0.5).
Adjust Fold
- 2
To reset the value to “0”
Press the (Clear) button.
To cancel the setting
Instead of going on to step e, press the button to return to step q.
Repeat step 8.
(1) Are the folded line and stapled position
aligned?
No
Go on to step 9.
(2) Is the stapled/folded line at the center of
the paper?
No
(3) Press the button to end the fine
adjustment.
The display returns to step 2 state.
Yes
Yes
To Next Page
