Page #119 background imageLoading...
Page #119 background image
2
101
When Messages Appear
4
Troubleshooting
Message Status and Solution
Check position of options
Press ** to continue
Status: When the slitter module is necessary for the
JOB.
Solution: Check the position of the slitter unit.
Gutter Slit NG area
Check position of options
Press ** to continue
Status: When the slitter is performing the JOB with slits
in the range of 55–60 mm.
Solution: Adjust the position of slits.
SLOT WRONG
The creaser tools are set in the wrong
direction for this JOB program
** : to continue
to clear
Status: The creaser tool in slot 1/slot 2 are not set in the
correct direction.
Solution: Press the STOP/TEST key as displayed to
continue the JOB.
To clear the error, pull out the tool and turn it
for the correct direction, and then press the
STOP key.
