Programming a JOB
58
Cut Trim Mode
Full Bleed Mode
: This chops up the area ahead of the fi rst cut position, the area behind
the last cut position, and the gutters of 48.9 mm or shorter, then drops
them into the waste box.
No Bleed Mode
: This chops up the gutters of 48.9 mm or shorter and drops them into the
waste box.
Process All
: All of the cut pieces are ejected to the exit tray. This chops up the gutters of
42 mm or shorter and drops them into the waste box. After the last cut, the
gutters of 67 mm or shorter are chopped up.
• Full bleed mode
0–48.9 mm
49.0 mm or more
49.0 mm or more
67.0 mm or more
0–48.9 mm
0–66.9 mm
Chopped up
Chopped up
Chopped up
Chopped up
Chopped up
Not chopped up
Document feed direction
Document feed direction
REFERENCE
Lead
edge of
document
First cut
Last cut
The area between two cuts shown
are chopped up and dropped into the
waste box.
Area processed
in Cut trim mode
To Next Page
