3. Assembling the frame
3.1 Assembling the frame components
–
Assemble the frame components as shown in the illustration.
–
Adjust set screw 10 so that the frame is stable.
All four of the frame supports must be firmly on the ground!
3.2 Assembling the table plate and fitting it on the frame
–
Screw the
drawer 12
with its brackets beneath the table plate.
–
Screw the
main switch 7
on the right-hand side beneath die table plate.
–
Screw the
cable conduit 6
behind the main switch 7 beneath die table plate.
–
Screw the
holder 5 for the mains-lead cleat
behind the cable conduit 6 under the
table plate.
–
Attach
bracket 4
with the electro-pneumatic sewing-foot lift (FLP) with screws and
washers beneath the table plate.
The table plate is factory-fitted with three screw nuts for this purpose.
–
Attach
oil collector 8
with nails beneath the table-plate opening.
–
Attach
table plate 13
to the frame with wood screws (8 x 32).
Its alignment on the frame is indicated by the dimensions in the sketch.
–
Insert
reel stand 3
in the hole in the table plate and attach with screws and
washers.
Fit and align the thread holders and guides.
The thread holders and guides must be vertically in line.
–
Insert
stoppers 1 and 2
in the cable-grommet holes.
3.3 Adjusting the working height
The working height can be adjusted between 750 and 950 mm
(measured to the upper edge of the table plate).
–
Undo screws 9 on both frame spars.
–
Adjust the table plate vertically to the desired working height.
Top prevent tilting, pull the table plate out or it push in by the same distance on
both sides.
The scales 11 on the outside of the spars serve as adjustment aids.
–
Tighten both screws 9.
