73
EN
Figure 18 - Unscrew the saddle clamp and adjust the saddle.
5. Check that the saddle yissllalignedwiththebike.
6. Tighten the Allen screw 8 of the saddle clamp to lock the saddle.
Figure 19 - Check alignment and ghten the saddle clamp.
7. Check whether the saddle y can turn or move up and down.
4
If the saddle can still move, the quick release 8 is not tight enough.
8. Carefully step onto the e-bike and sit on the saddle y.
