9. Turn the pedal estothelowestposionandplaceyourheelonthepedal.
4
Ifyoumustfullyextendyourlegtoreachthepedalinthelowestposition,yoursaddleistoo
high.
4
If you can stand with both feet flat on the ground, your saddle is too low.
6
CAUTION
Ҍ Aloosesaddlecanmoveatunexpectedmomentsandleadtohazardoussituaonsor
accidents.Alwaysmakesureyouhavesucientlyghtenedthesaddleclampandthatthe
saddlecannotmakeanyunexpectedmovements.
4.8.1.2. Angle and horizontal posion
1. Adjust the angle of the saddle yusingthetwoadjusngscrewsunderthesaddle.
2. Tilt the saddle y to the desired angle.
4
Optional:Loosenbothadjustingscrewsslightlyandslidethesaddleforwardsorbackwardsto
adjust the horizontal position of the saddle.
3. Lockthesaddleposionbyghteningtheadjusngscrewswiththeghteningtorque
indicated on the underside of the saddle clamp. Use a torque wrench for this.
6
WARNING
Theclampshouldbexedwithinthemarkingonthesaddlerails.Aachthesaddlewithinthe
marking.
Figure 20 - Loosening adjusng screws and adjusng saddle posion.
4.8.2. Adjusngthehandlebars
Once you have adjusted the saddle correctly, you can adjust the handlebars for a comfortable
cyclingposion.
Youcanadjusttheheightofthehandlebarsasfollows:
