dutch id SHADOW - Page 78

75
EN
1. Place the e-bike on the stand p.
2. Slightlyunscrewtheboomscrewonthesideofthehandlebarstem.
3. Carefully pull the handlebars towards you to adjust the distance between the saddle y and
handlebarsunlyouidenfythedesiredridingposture.
4. Reghtentheboomscrewonthesideofthehandlebarstem.
Figure 21 - Adjusng the posion of the handlebars for a comfortable riding posture.
5. Slightly unscrew the top two screws on the front of the handlebar stem.
6. Tiltthehandlebarsupwardsordownwardsunlthehandlesareatthedesiredangle.
7. Ensure that you can comfortably reach all controls 2 and brake levers 17. You must rotate
thebrakeleversintothecorrectposiononceyouhaveadjustedtheheightofthehandlebars
(see chapter 4.8.3)
Figure 22 - Adjusng the angle of the handlebars for a comfortable riding posture.
