dutch id SHADOW - Appendix 2; Summary of Tightening Torques

94
Appendix2 Summaryofghteningtorques
1 2
4
3
5
6
7
9
q
8
Figure 32 - Summary of ghtening torques.
1 Bosch display holder on handlebars
2 Stem(2x)
3 Saddle
4 Seatpost
5 Spoke magnet speed sensor
6 Crank bolt
7 Thru-axle
8 Rearaxlenut
9 Dropout bolts
q Speed sensor
1 Nm
10-15Nm
9-10Nm
9-10Nm
1 Nm
40Nm
10Nm
40Nm
10Nm
3 Nm
