dutch id SHADOW - Adjusting the Brake Levers

76
8. Use the markings on the handlebars to check that the handlebars are correctly aligned in the
centre.
Figure 23 - Checking the alignment of the handlebars.
9. Firmlyghtenthescrewsofthehandlebarstemtolockthehandlebarinthecurrentposion.
4
If you are still able to move the handlebar, you have not tightened the screws enough.
6
CAUTION
• Loosehandlebarscanmoveatunexpectedmomentsandleadtohazardoussituaonsor
accidents.Alwaysmakesureyouhavesucientlyghtenedthescrewsofthehandlebarstem
andthatthehandlebarcannotmakeanyunexpectedmovements.
4.8.3. Adjusngthebrakelevers
Iftheposionandangleofthehandlebarshavebeenadjustedcorrectlybutyoucannot
comfortablyreachthebrakelevers,youcanadjustthem:
1. Loosenoneofthescrewsonthegripslightlyunlthebrakelever17 can rotate around the
handlebars.
2. Turnthegripunlitisatananglethatallowsyoutoreachiteasily.
3. Tighten the screw on the handlebar clamp of the brake lever.
4
Optional:Toallowthebrakeleverstobeoperatedwithsmallerhands,youcanalsoreduce
the distance between the brake lever and the handgrip by turning the adjusting screw on the
brake levers clockwise.
6
CAUTION
Ҍ Oncethebrakelevershavebeenadjusted,itisimportanttocheckthatthebrakessllwork
correctly.Ifyoucansqueezetheleverallthewaytothehandgrip,thebrakeisnotght
enoughandthebrakewillnotworkopmally.
Ҍ Consult your dealer for the correct adjustment of the brake levers.
